尺寸：107*75*51.5MM 重量：220g 加配件：450g。
性能参数：
打印方式： 行式热敏打印
打印速度 >90mm/s
打印头寿命：100km
分辨率： 203dpi（8dot/mm）
有效打印宽度 ：48mm（384点）
可用纸张宽度： 58±01mm
纸仓容量 直径φ≤50mm
纸张类型 热敏纸
电源(可选）： 可充电锂电池
电池 规格： 锂电：7.4VDC/1500mA
充电方式： 外置充电器 9V/1.5A
语言：支持多国语言
打印参数：支持下载Logo商标打印
字符大小：
384点/行
Font A:12*24点,1.5(宽)*3.0(高)毫米
Font B:9*17点,1.1(宽)*2.1(高)毫米
简/繁体:24*24点,3.0(宽)*3.0(高)毫米
字符中文：国标一.二级汉字库 24x24点 支持18030大字库，支持台湾，香港繁体
西文： ANK字符
扩展字符表：OEM437/Katakana/OEM850/OEM860/OEM863/OEM865/West Europe/
Greek/Hebrew/East
Europe/Iran/WPC1252/OEM866/OEM852/OEM858/IranII/Latvian/Arabic/PT151,1251/OEM747/WPC1257/Vietnam/OEM864/Hebrew/WPC1255/Thai
命令仿真： 兼容ESC/P0S/STAR 指令集
通信接口： 标配RS232/USB接口，蓝牙4.0/SPP、BLE、SOCket协议或红外/IRCOMM协议可选
驱动程序：Win2000，Win2003，WinXP，WinVista，Win7,Win8,win10,Linux
兼容 ESPON,SAMSUNG
使用环境 -10～50℃(温度)，10～90%（湿度）
迷你蓝牙打印机是结合USB接口，串口和蓝牙通信接口一起便携式热敏打印机。打印机可以采用车载充电器,可充电电池(根据指定的模式)。这些特殊功能使它成功地应用于多种仪器,手持数据打印
It applies mobile products to supporting the use, and suited to outdoor work environments.
The feature has small size、light weight、reliable performance、simple to connect、easy to use.
Applications:
The mobile police system
The tobacco distribution system
The utility meter reading system
The mobile office / mobile logistics systems
The portable instrumentation
The testing equipment, ancillary equipment.
Low operating costs (no ribbons, ink cartridges)
Weight: about 400g (including accessories: lithium-ion batteries, cable, test paper)
Chapter 2: Parameter Details
Printing Method: Thermal line printing
Print speed: 90mm/sec
Reliability TPH Life: 100km
Resolution: 203DPI (8dot/mm)
Printing Width: 48mm (384dot)
Paper Width: 58±01mm
Roll Diameter: φ≤50mm
Paper Type: Thermal Paper
Power supply (optional): rechargeable lithium batteries
Battery: Lithium: 7.4VDC/1500mA,
Charging mode: DC 9V/1.5A
Support the battery display function
Print parameters: support to download the Logo trademark
Character size:
The 384 - point/line
The Font A: 12 * 24 points, (wide) 1.5 * 1.5 (high) mm
The Font B: 9 *17points, 1.1(wide) * 2.1 (high) mm
Jane/traditional: 24 * 24 points, (wide) 3.0 * 3.0 (high) mm
Printing Chinese character: Chinese: simplified Chinese 24x24 point. support 18030 font library, support Taiwan and HK traditional(complex font)
ANK: ANK characters
Extended character table:
OEM437/Katakana/OEM850/OEM860/OEM863/OEM865/West Europe/Greek/Hebrew/EastEurope/Iran/WPC1252/OEM866/OEM852/OEM858/IranII/Latvian/Arabic/PT151,1251/OEM747/WPC1257/Vietnam/OEM864/Hebrew/WPC1255/Thai
Emulation: ESC/POS/STAR command
Interface: standard RS232/USB, Bluetooth 4.0/SPP、ble、socket t agreement or infrared/IRCOMM agreement (optional).
Drivers: Win9X/Win2000//Win2003/Win Vista/ Win 7/Window XP /win 8/WIN10/WIN11/linux
Compatible with ESPON,SAMSUNG
Working Temperature: -10～50℃
Humidity: 10～90%
